D710 Desk Telephone
A business phone designed for HD audio, performance and affordability
The D712 is a state-of-the-art, full-featured IP desk phones for small or large scale deployments suitable for use in a multitude of business scenarios. Supporting four SIP identities and five programmable keys with built in LEDS for visual call indication alerts, the D712 blends an elegant utilitarian design for high usability with high performance and affordability.
Dear Customers and Partners. Snom hereby informs that the Snom D710 phone has reached END OF SALE (EOS) status in September 2017 and will be replaced with the Snom D712. For further information, please read the following EOS Announcement
This is a carousel. Use Next and Previous buttons to navigate.
Images Slider
This is a carousel. Use Next and Previous buttons to navigate.
Phone Features
- 4 SIP identities / accounts
- XML browser
- Call lists for dialed, received, missed calls
- Local directory with 1000 entries
- Multiple language support
- DTMF in-band / out-of-band / SIP-INFO
- Interoperable with all major IP PBX platforms
- Speed dialing
- URL dialing
- Local dial plan
- Automatic redial on busy
- Call completion (busy/unreachable)(2)
- Caller identification
- Call waiting
- Call blocking (deny list)
- Auto answer
- Hold
- Music on hold(2)
- Handling of up to 4 simultaneous calls
- Blind and attended transfer
- Call forwarding
- 3-way conferencing on the phone
- Extension monitoring, call pickup(2)
- Call park, call unpark(2)
- Multicast paging
- DND mode (do not disturb)
- Keyboard lock
- Client matter code (CMC)(2)
- Unified communications ready
Audio
- Codecs:
- G.711 A-law, μ-law
- G.722 (wideband)
- G.726, G.729AB, GSM 6.10 (FR)
- Built-in assignable ringtones
- Comfort Noise Generator (CNG)
- Voice Activity Detection (VAD)
Setup
- Configurable through web interface
- Provisioning:
- Automatic loading of settings via HTTP/HTTPS/TFTP
- DHCP Options 66/67
- Snom Redirection Service
- Remote management via TR-069 / TR-111
Protocols
- SIP (RFC3261)
- DHCP, NTP
- HTTP / HTTPS / TFTP
- LDAP (Directory
User Interface
- Localization (language, time, dial tone)
- Red LED for call indication / message waiting
- 4 context sensitive keys
- 5 programmable line / function keys with green LEDs
- Paper inlay for labeling of function keys
- Dedicated message key
- Audio keys with LED indication: Mute, speakerphone, headset
- Volume key
- 4-way navigation key
- OK and Cancel
- Menu-driven user interface
Security
- 802.1X Authentication and EAPOL
- Transport layer security (TLS)
- SRTP (RFC3711), SIPS, RTCP
- HTTPS server/client
- Password-protected web interface
- VPN support
- VLAN (IEEE 802.1Q)
- LLDP-MED, RTCP-XR
Specifications, Weights and Dimensions
(2) If supported by PBX
- Dimensions (approx.):
- 7.28" x 3.54" x 8.66"
- With desk stand: "7.28" x 8.46" x 6.81"
- Weight (approx.): 1.7 lbs
- Input voltage: 5 Vdc (SELV)
- Power supply: PoE or 5Vdc power adapter(1)
- Handset: 4P4C connector
- Headset: 4P4C
- Hearing aid compatible (HAC) handset
- Environmental conditions:
- Ambient temperature: 0°C to 35°C (32°F to 95°F)
- Storage temperature: -10°C to 45°C (14°F to 113°F)
- Humidity: 5% to 95% (non-condensing)
- Included in delivery:
- Phone unit
- Footstand
- Handset with cord
- Ethernet cable
- Quick Start Guide
- Color: black
- Warranty: 3 Years
- Part Number: 00004235 (all markets)
- APN: 80-S000-00
(2) If supported by PBX
APN numbers for optional accessories
-
26-350200-3UL Power Adapter Snom A6 / US clip
89-S015-00 Snom EHS Advanced
00-S013-00 Wallmount plate for 7-series
89-4083-00 A100D Binaural headset
89-4082-00 A100M Mono headset
